Window Espag Systems

The MILA GARANT Espag System is a high-performance solution for Scandinavian windows, designed to deliver exceptional security, durability, and ease of use. Built with robust mini-hooks that can withstand forces up to 6,000 N, the system ensures strong entry resistance as standard. With standardized dimensions, corrosion-resistant surface treatment, and options to suit various backsets, it combines reliable burglar protection with efficient stock handling and simple installation.

Technical Specification:

• Exceeds the requirements of RC2 (EN1627 - 1630)
• Always same distance from side or top/bottom
• Same milling regardless of solution and sash size
• Central locking optional!

Product Features:

• Solid mini-hook withstands a side pressure of up to 6.000N (600kg) without breaking or bending
• Surface treatment – min. 240 hours according to EN1670, Grade 3
• 16mm faceplate – suitable for standard EURO groove
• Backset 19, 25, 28, 33 and 40
• Loose connecting pieces and espags
